Product Overview
The Fully Automatic Wagon Plate Line is a highly versatile, customizable manufacturing system specifically engineered to meet the diverse production needs of the commercial vehicle and logistics industries. Designed for maximum operational efficiency, this advanced metal carriage board forming machine seamlessly transforms high-strength steel coils into premium, structurally superior wagon plates and truck side panels. By integrating intelligent PLC automation, automated hydraulic punching, and continuous flying cut-off mechanisms, this fully automatic line empowers manufacturers to produce bespoke, high-precision carriage boards with minimal human intervention. It is the ultimate turnkey solution for fabricators seeking to maximize throughput, reduce labor costs, and deliver custom-tailored truck body components to the global transportation market.
- Fully Automatic & High-Efficiency Operation: Engineered for continuous, high-speed production, the machine automates the entire workflow from coil feeding and leveling to roll forming, punching, and cutting. This fully automatic capability drastically reduces manual labor requirements, minimizes operational errors, and maximizes daily output to meet large-volume market demands.
- Ultimate Customizability & Flexible Forming: Designed to accommodate bespoke client requirements, the machine’s forming stations and tooling can be easily adjusted or swapped. Whether you need specific corrugation profiles, unique rib designs, or custom interlocking mechanisms, this customizable carriage board forming machine can be precisely tailored to manufacture your proprietary truck body systems.
- Integrated Automatic Hydraulic Punching: Built for manufacturing efficiency, the system includes a high-speed hydraulic punching unit that automatically creates precise mounting holes, rivet holes, and service openings directly during the forming process. The punching positions and patterns are fully programmable via the PLC, eliminating secondary drilling and streamlining the assembly process.
- Continuous High-Speed Flying Cut-Off: Equipped with a robust hydraulic flying shear mechanism, the machine dynamically tracks the moving wagon plate to execute clean, burr-free cuts at exact lengths without stopping the production line. This seamless cutting technology ensures high throughput while maintaining strict dimensional tolerances for every custom board.
- Intelligent PLC Automation: Governed by a cutting-edge Programmable Logic Controller (PLC) and a user-friendly touchscreen HMI, the machine offers effortless operational control. Operators can store and recall custom profiles, set production lengths, and manage batch quantities with ease. The intelligent system ensures high repeatability and rapid recipe switching for different OEM orders.
- Heavy-Duty Frame & Surface Protection: Built with a reinforced, stress-relieved steel chassis to absorb intense forming forces, the machine guarantees stable, continuous operation. Its smooth, hard-chromed rollers and precision guide systems protect galvanized or color steel coatings from scratching, ensuring the final wagon plates maintain their superior corrosion resistance and long-term durability.
The high-precision, customizable metal carriage boards produced by this fully automatic line serve as essential components across a wide range of commercial transport sectors, including:
- Heavy-Duty Freight & Box Trucks: Manufacturing durable, custom-sized corrugated side panels and rear doors for long-haul trailers, semi-trailers, and dry freight carriers.
- Logistics & Delivery Fleets: Producing lightweight, high-strength wagon plates for courier vans, parcel delivery trucks, and urban logistics vehicles tailored to specific fleet requirements.
- Agricultural & Dump Trucks: Creating heavy-duty, impact-resistant sideboards and tailgates for agricultural trailers, dump trucks, and mining transport vehicles operating in rugged environments.
- Specialized Cargo Carriers: Supplying robust, weather-resistant truck body panels for refrigerated containers, flatbeds, and specialized transport vehicles requiring unique panel geometries.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
