Product Overview
The Truck Side Board & Frame Beam Machine is a comprehensive, dual-purpose cold bending production line meticulously engineered for the advanced manufacturing of commercial vehicle bodies. Designed to maximize factory floor efficiency, this versatile equipment seamlessly integrates the roll forming of corrugated side boards with the precision bending of structural frame beams. Governed by an intelligent PLC control system and featuring integrated hydraulic punching and flying cut-off mechanisms, it allows manufacturers to produce both outer carriage panels and inner load-bearing frames on a single, automated line. This complete carriage panel cold bending equipment is the ultimate turnkey solution for truck body fabricators aiming to streamline assembly, reduce capital investment, and deliver structurally superior, perfectly aligned truck compartments.
- Dual-Function Versatility (Side Boards & Frame Beams): Engineered for maximum production flexibility, this machine can be configured to produce both the exterior corrugated side boards and the interior structural frame beams (such as C-channels or U-tracks). This dual-purpose capability eliminates the need for separate machines, significantly optimizing factory space and reducing overall equipment investment.
- Precision Cold Bending & Roll Forming: Utilizing advanced cold bending technology and meticulously calibrated heavy-duty forming stations, the machine ensures that every side board and frame beam features exact dimensional tolerances, crisp edges, and flawless structural straightness. This high precision guarantees perfect alignment during truck body assembly and superior overall chassis rigidity.
- Integrated Automatic Hydraulic Punching: Designed for manufacturing efficiency, the system includes a high-speed hydraulic punching unit that automatically creates precise mounting holes, rivet holes, and bolt slots directly during the forming/bending process. The punching positions are fully programmable via the PLC, eliminating secondary drilling and drastically reducing labor costs.
- Continuous Flying Cut-Off System: Equipped with a robust hydraulic flying shear mechanism, the machine dynamically tracks the moving profile to execute clean, burr-free cuts at exact lengths without stopping the production line. This continuous cutting technology maximizes throughput and ensures seamless, high-speed manufacturing of both panels and beams.
- Intelligent PLC Automation: Governed by a cutting-edge Programmable Logic Controller (PLC) and a user-friendly touchscreen HMI, the machine automates the entire workflow. Operators can effortlessly store and recall different profiles for side boards and frame beams, set production lengths, and manage batch quantities. The intelligent system ensures high repeatability and rapid recipe switching.
- Heavy-Duty Structural Frame & Surface Protection: Built with a reinforced, stress-relieved steel chassis to absorb intense bending and forming forces, the machine guarantees stable, continuous operation. Its smooth, hard-chromed rollers and precision guide systems protect galvanized or color steel coatings from scratching, ensuring the final components maintain superior corrosion resistance and long-term durability.
The highly precise, structurally superior side boards and frame beams produced by this machine serve as the foundational framework for modern commercial vehicle manufacturing, including:
- Box Trucks & Dry Freight Trailers: Manufacturing perfectly interlocking corrugated side panels and matching internal structural beams for long-haul and regional freight carriers.
- Heavy-Duty Dump & Mining Trucks: Producing robust, impact-resistant sideboards and heavy-duty frame beams designed to withstand extreme loads and harsh environments.
- Refrigerated & Specialized Cargo Vehicles: Supplying precisely aligned steel framing and exterior panels for insulated truck bodies, flatbeds, and specialized transport carriers.
- Agricultural & Livestock Trailers: Creating durable, weather-resistant carriage panels and structural supports for farm transport, livestock haulers, and agricultural equipment.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
-
