High Efficiency & Energy Saving Arc Single Panel Roll Forming Machine
Product Description
High Efficiency & Energy Saving Arc Single Panel Roll Forming Machine is a professional automatic cold roll forming equipment, integrating the core advantages of high efficiency, energy saving and customizable radian. It realizes one-stop automated production from automatic uncoiling, sheet leveling, precise feeding, progressive roll forming, arc shaping to fixed-length cutting and finished product collection, which is widely applied in construction, steel structure engineering, architectural decoration and metal deep processing industries. It is mainly used for manufacturing arched roof panels, curved exterior wall cladding, decorative arc components, garage door panels, canopy panels and other high-quality metal single panel products.
As the core selling point, the high efficiency & energy saving performance of this machine is outstanding. It adopts an optimized variable frequency drive (VFD) system and an energy-saving main motor, which can automatically adjust the power output according to the production load, reducing idle energy consumption by 20%-30% compared with traditional equipment. The continuous forming speed can reach 15-35m/min, which is 30% higher than ordinary arc forming machines, and it can complete the forming of large batches of products in a short time. At the same time, the equipment adopts a streamlined structural design, reducing mechanical friction loss, further reducing energy consumption while ensuring stable operation, helping enterprises save production costs and achieve green production.
In addition to high efficiency and energy saving, the machine is also equipped with a flexible and adjustable radian customization function, which can perfectly meet the diverse needs of different projects. It supports free customization of arc radians, ranging from small-radius arcs (R≥30mm) to large-span arcs (R≤20m), and can be precisely adjusted according to the specific design requirements of customers. The radian positioning is accurate, with an error controlled within ±0.1mm, ensuring that each metal single panel has a uniform curvature, smooth surface and consistent dimensional accuracy. Compared with traditional fixed-radian forming equipment, it avoids the trouble of replacing roller sets when switching different radian specifications, adopts a quick micro-adjustment mechanism, and can complete radian adjustment within 10-15 minutes, further improving production flexibility and efficiency.
In terms of structural stability and durability, the equipment adopts a heavy-duty integrated welded steel frame, which is processed by high-temperature annealing to eliminate internal stress, effectively enhancing the rigidity and stability of the whole machine. It can operate stably for a long time under high-load production conditions, with low vibration and low noise, avoiding the impact of equipment shaking on forming precision. The core forming system adopts multi-pass progressive roll forming technology, and the forming rollers are made of high-quality alloy steel, through precision turning, quenching and hard chrome plating treatment (surface hardness up to HRC 58-62). This not only ensures the wear resistance and corrosion resistance of the rollers, prolonging their service life to more than 5 years, but also ensures that the metal sheet is gradually deformed during the forming process, without scratches, wrinkles, springback or material damage.
For operational convenience, the equipment is equipped with an intelligent PLC control system and a large-size touchscreen human-machine interface, which is simple and intuitive to operate. Operators can easily set key parameters such as forming speed (15-35m/min, stepless adjustable), processing length, arc radius and cutting frequency, and can store up to 50 sets of product specifications and radian parameters, realizing one-key switching of production tasks. The control system is also equipped with automatic fault diagnosis, overload protection and emergency stop functions, which can quickly alert and locate faults, effectively reducing downtime and ensuring safe and stable production.
This equipment has strong material adaptability, and can process various common metal sheets, including color-coated steel, galvanized steel, aluminum-magnesium-manganese alloy, stainless steel and other materials, with applicable sheet thickness ranging from 0.3mm to 1.5mm, and applicable sheet width can be customized according to customer needs (300mm-1200mm). In addition to radian customization, we can also provide personalized customization services according to customer requirements, such as adjusting the forming profile, improving processing precision, and optimizing energy-saving performance, to fully meet the individual production needs of different enterprises.
With the dual advantages of high efficiency, energy saving and flexible radian customization, plus high forming precision, simple operation and low maintenance cost, this machine is an ideal production equipment for metal processing enterprises, steel structure manufacturers and building materials factories. It can help enterprises reduce manual operation, save energy costs, improve product quality and production efficiency, and enhance market competitiveness in the field of arc metal single panel production.
♦ COMPANY PROFILE:
Hebei Xinnuo Roll Forming Machine Co., Ltd., not only produce different types of professional roll forming machines, but also develop intelligent automatic roll forming production lines, C&Z shape purline machines, highway guardrail roll forming machine lines, sandwich panel production lines, decking forming machines, light keel machines, shutter slat door forming machines, downpipe machines, gutter machines, etc.
Advantages of Roll Forming A Metal Part
There are several advantages of using roll forming for your projects:
- The roll forming process allows operations such as punching, notching, and welding to be performed in-line. Labor cost and time for secondary operations are reduced or eliminated, reducing part costs.
- Roll form tooling allows for a high degree of flexibility. A single set of roll form tools will make almost any length of the same cross-section. Multiple sets of tools for varying length parts are not required.
- It can provide better dimensional control than other competing metal forming processes.
- Repeatability is inherent in the process, allowing easier assembly of roll formed parts into your finished product, and minimizing problems due to “standard” tolerance build up.
- Roll forming is typically a higher speed process.
- Roll forming offers customers a superior surface finish. This makes roll forming an excellent option for decorative stainless steel parts or for parts requiring a finish such as anodizing or powder coating. Also, texture or pattern can be rolled into the surface during forming.
- Roll forming utilizes material more efficiently than other competing processes.
- Roll formed shapes can be developed with thinner walls than competing processes
Roll forming is a continuous process which converts sheet metal into an engineered shape using consecutive sets of mated rolls, each of which makes only incremental changes in the form. The sum of these small changes in form is a complex profile.
